Automatic Enameled Wire Cutting and Stripping Machine
Product Categories: Cutting and Stripping
Model: B-07
Brand: ZHAOZHUANG
Online InquiryAutomatic Enameled Wire Cutting and Stripping Machine
-
Suitable for cutting and stripping enameled wires of 0.25-1.2mm diameter
-
Also works as a cutting machine only, and the maximum wire cutting diameter is 1.2mm.
| Cutting Length | 0.01MM-10M |
| Cutting tolerance | (0.1-0.2)mm*L (L=Cutting length) |
| Wire diameter | 0.25-1.2mm |
| Speed | 15000pcs/h (Cutting length=50mm) |
| Tool material | hard tungsten steel blade |
| Cutting quality | excellent |
| Wheel pressure adjustment | Yes |
| Speed adjustment | 1-6 |
| Power supply | AC220V/50HZ |
| Rated Power | 100W |
| Max. Power | 200W |
| Weight | 21KG |
| Dimensions | 340x387x230mm(L*M*H) |
