Automatic Enameled Wire Cutting Stripping machine
Product Categories: Cutting and Stripping
Model: B-09
Brand: ZHAOZHUANG
Online InquiryAutomatic Enameled Wire Cutting Stripping machine
-
Suitable for cutting and stripping enameled wires of 0.7-3.0mm diameter
-
Also works as a cutting machine only, and the maximum wire cutting diameter is 2.5mm.
-
Adopts three round knives to scrape paint at 360 degree position and increase the repeat life of the blade. Tungsten steel is durable and can be be grinded and used again.
- Stripping speed:
For 1.0mm enameled wire: length=43 cm, each ends stripping=3.5 cm, the fastest speed: 25pcs/min. 1500pcs/h, and the slowest speed: 14pcs/min. 840pcs/h;
For 1.2mm enameled wire: length=39cm, each ends stripping=3.5 cm, the fastest speed: 26pcs/min. 1560pcs/h, and the slowest speed: 15pcs/min. 900pcs/h.
Automatic Enameled Wire Cutting Stripping machine
| Cutting Length | 0.01MM-10M |
| Cutting tolerance | (0.1-0.2)mm*L (L=Cutting length) |
| Wire diameter | 0.7-2.5mm(Max. 3mm can be customized) |
| Speed | 2400pcs/h (Cutting length=100mm, head/tail stripping=50mm) |
| Tool material | Hard tungsten steel knife |
| Cutting quality | excellent |
| Wheel pressure adjustment | Yes |
| Speed adjustment | 1-6 |
| Power supply | AC220V/50HZ |
| Max. Power | 280W |
| Weight | 21KG |
| Dimensions | 560x500x300mm(L*M*H) |
