Automatic Big Cable Cutting Stripping Machine
Product Categories: Cutting and Stripping
Model: XC-970A
Brand: ZHAOZHUANG
Online InquiryAutomatic Big Cable Wire Cutting Stripping Machine
XC-970A belongs to the latest generation of automatic cutting and stripping machine which is able to process up to 70 squares wire. Adjustable stripping parameters, high-performance and simple operation with color screen, all of these advantages have XC-970A become a very popular type of stripping machines worldwide. With 99 sets of program storage function, it is very convenient for operators to process different sizes of wires. Wheel jumping design help to keep available space for stripping wires. Another special function is 3 layers stripping for coaxial wire whose stripping parameters can be set alternately.
Automatic Big Cable Cutting Stripping Machine
|
Area of cutting wire core |
4-70mm2 |
|
Cutting length |
0.1mm-100m |
|
Cutting tolerance |
less than 0.002*L (L = cutting length) |
|
The diameter of the catheter |
up to 18mm (24mm can be customized) |
|
Blade Material |
High quality steel blade |
|
Stripping speed |
2000-3000 roots per hour(100mm length per unit) |
|
Power |
1000W |
|
Driving mode |
8-wheel drive (silent hybrid stepping motor, 0.1mm forward per step) |
|
Size |
400*515*345mm |
|
Weight |
79kg (wooden case 21kg) |
