Large Cable Cutting and Stripping Machine
Product Categories: Cutting and Stripping
Model: XC-70
Brand: ZHAOZHUANG
Online InquiryLarge Cable Wire Cutting and Stripping Machine
1. Control system is the latest 32-bit Cortex-M3 core processor, with 7-inch inustrial touch screen, easy to operate, high stability.
2. It adopts 8 wire feeding wheels with outer diameter of 45mm. The contact area between the roller and the wire is larger, the feeding wire is more stable and the feeding length is more accurate.
3. the control system is highly integrated, greatly reducing the system failure rate.
4, With large-capacity memory, can store 100 sets of parameters at the same time, easy tooperate;
5. The distance between the wheels of the front and rear rollers is controlled by the motor. It only needs to input the wire diameter and it is easy to operate.
6. The upper and lower rollers are synchronously adjusted, the center point of the blade is always unchanged, and the processing of large or small wires does not require adjustment of the blade.
7. the machine is all driven by the motor, does not require compressed air, versatility.
Large Cable Wire Cutting and Stripping Machine
|
Area of cutting wire core |
4-70mm2 |
|
Cutting length |
0.1mm-100m |
|
Cutting tolerance |
less than 0.002*L (L = cutting length) |
|
The diameter of the catheter |
up to 18mm (24mm can be customized) |
|
Blade Material |
High quality steel blade |
|
Stripping speed |
2000-3000 roots per hour(100mm length per unit) |
|
Power |
1000W |
|
Driving mode |
8-wheel drive (silent hybrid stepping motor, 0.1mm forward per step) |
|
Size |
400*515*345mm |
|
Weight |
79kg (wooden case 21kg) |
